Black / 250W/90KM/25KM/h
Introduction to the exploded view of the F10 parts.
The detailed exploded view of the vehicle is intended to give you a better overview for your purchase. If you have any further questions about the F10, you can find more information below.
1
Equipped with a powerful 250 watt motor.
In 3-speed mode, the motor delivers 50 Nm of torque in just 2 seconds. Designed with a sine wave structure, the motor allows you to effortlessly control your riding speed across gears 1 to 3, providing a customizable and intuitive riding experience. Yoloway's rear wheel motor has received international certifications in accordance with CE and RoHS standards.
48V 13Ah battery from Samsung
Using the newly developed 18650 cells from Samsung SDI, each lithium-ion cell has a diameter of 21 millimeters and a length of 75 millimeters, forming a 48V 13Ah configuration. Yoloway Bike uses a quick-release design for the sealed battery, with multiple layers of protective coating that achieve an IPX-4 waterproof rating. The battery has a detachable charging cable and has the international certification UL 2271.
Kompakt und Faltbar
- Platzsparendes Design: Einfach zusammenklappbar für mühelosen Transport.
- Passt in den Kofferraum: Leicht zu verstauen im Auto oder Wohnwagen.
- Ideal für Unterwegs: Perfekt für Pendler und Abenteurer.
- Maximale Flexibilität: Nehmen Sie Ihr F10 überall mit!
The main features
-
Hidden battery protection
The F10 features a foldable and removable hidden battery structure with a sealed design that achieves an IPX-4 waterproof rating, ensuring longer battery life.
-
Folding size
F10 has multiple folding functions and can easily be placed in the trunk of a car. The dimensions after folding are: 90 centimeters long, 81 centimeters high and 60 centimeters wide.
-
20" x 3" puncture proof tires
With 20*3 fat tires and a front fork, the F10 can conquer various road conditions including flat roads, mountain trails, snow-covered fields, gravel pavements and more.
-
Powerful lighting configuration
The F10 is equipped with a powerful lighting system, including front lights and a rear light.
-
LCD display
The F10 e-bike is equipped with an advanced M5 display. It offers 5 electronic support levels and shows you all important riding data at a glance: energy level, current speed, pedal support level, kilometers traveled, trip information and odometer.
-
Pedestrian warning bell
The pedestrian warning bell is designed to warn pedestrians, encourage careful navigation and increase safety while driving.
-
Shimano 7-speed
The Shimano 7-speed shifter ensures smooth gear shifting, while the motorcycle-style twist shifter allows easy management of the electric bike's speed.
-
Mechanical brakes
The sensitive braking system with front and rear 160 mm brake discs provides sufficient braking power over short distances, even in wet or dry conditions.
Assembly instructions
It's time to set up your F10 e-bike! We've prepared a detailed installation video for you. Whether you're assembling it for the first time or need a refresher, this video will walk you through the process step by step to ensure your F10 is assembled correctly and ready for your next adventure. Check out our video on YouTube channel .
Specifications
Specifications
brand
type
Model
Frame
Front fork
Shock absorbers
Tires
battery
Sensors
crank
cassette
Side stand
Bicycle light
Front brake
Rear brake
Brake discs
Torque
Loading time
Maximum speed
-
Specifications
-
geometry
-
In the box
-
Battery 624 Wh
-
Range 90 km
-
Motor
250W (peak 350W) -
Advertisement
LCD display -
Maximum load capacity
400 lbs / 181kg -
Total weight of the bike
63.9 lbs/29 kg -
Recommended height
5'1" to 6'2"(155 cm -188 cm) -
Intelligent pedal assistance
0~5 pedal assistance levels -
Tires
20" x 3" puncture proof tires -
Lighting functions
Headlights and taillights -
Front suspension
With lockout and damping adjustment
-
A -- Top tube length 62 cm
-
B -- Handlebar length 61 cm
-
C -- Head tube length 14.5 cm
-
D -- Seat tube 38 cm
-
E -- Chainstay 43.5 cm
-
F -- Wheelbase 114 cm
-
G -- Total length 170 cm
-
H -- Wheel size 55 cm
-
I -- Handlebar height 111cm-123cm
-
J -- Minimum seat height 75 cm
-
K -- Maximum seat height 93 cm
-
1* Electric bike
-
1* User Manual
-
2* Pedals
-
1* front wheel
-
1* Front mudguard
-
4* Allen keys 2* Open-end wrenches
-
2* keys
-
1* Charger
-
1* Saddle
FAQ
Does my size fit the F10?
Does my size fit the F10?
Recommended rider is 5'1" to 6'2"/155cm-188cm tall.
To which regions does shipping take place?
To which regions does shipping take place?
Our shipping services cover the European Union (excluding Malta, Cyprus and the outermost regions of the EU) and the United Kingdom. Please note that deliveries to PO boxes are currently not possible.
How long does it take for my order to arrive?
How long does it take for my order to arrive?
Typically, your order will be dispatched within one business day of placing the order and shipping takes approximately 3-5 days.
Will my Yoloway e-bike be delivered pre-assembled?
Will my Yoloway e-bike be delivered pre-assembled?
Your e-bike arrives 85% assembled. There are just a few pieces to put into place once you take the bike out of the box. Unpacking and installation instructions can be found here on our YouTube channel .
Do you offer warranty and customer support?
Do you offer warranty and customer support?
Yes, we stand behind the quality of our products. All Yoloway e-bikes come with a 1-year warranty for a worry-free riding experience. In addition, we offer excellent customer support to answer any questions or concerns you may have. Your satisfaction is our top priority, and we are here to make sure you have a fantastic e-bike experience.
Can my Yoloway e-bike be serviced at any bike shop?
Can my Yoloway e-bike be serviced at any bike shop?
Yes, any bike shop can repair your bike. If you need help with your order, our customer service team is happy to help. Please email us at support@yolowaybike.com.
